Réamhrá Táirge
The system for entering the prison or for the mobile operator communication system has special requirements of that user terminal in the communication coverage area, according to the user's classification, communication permission or communication blocking. For special target users, according to communication system difference, it is also possible to conduct further communication checks.
Áirítear leis an gcóras rialaithe cumarsáide an córas cumarsáide seo a leanas: CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, 3G WCDMA, 4G LTE agus mar sin de chomhartha cumarsáide soghluaiste.
Is féidir an córas iomlán a shaincheapadh de réir riachtanais na gcustaiméirí ar leith, agus is féidir leis an gcomhcheangal riachtanais chórais cumarsáide speisialta de thíortha nó de réigiúin éagsúla a chomhlíonadh go solúbtha.
Áirítear le feidhmeanna bunúsacha an chórais:
● According to different communication system of in all coverage areas to terminal uers IMSI capture
● To captured IMSI filtering whitelist and blacklist
● Whitelist users release back to the macro network for normal communication.
● Not Whitelist user communication blocking and shielding
● Conduct communication monitoring for blacklist users who meet certain conditions, Or with other device for positioning
● 20W coverage distance directional antenna jamming diameter 1000-2000M, omnidirectional antenna jamming radius 500-800M.
● The detailed functions of the various communication systems included: Macro network scanning, Automatic and manual network settings, IMSI / ESN capture, Black and white list setting and filtering, Access policy configuration, In the network UE status monitoring, Report terminal signal strength.
● For TDD-LTE and FDD-LTE, the captured UEcan be redirected to the specified 2G and 3G systems.
Sonraíocht Táirge
Banda minicíochta oibre | CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, 3G WCDMA, 4G LTE agus mar sin de | |
Cumas | Tonn iompróra uasta fráma bosca aonaid: 4 | |
Feidhmíocht | Cumhacht aschuir uasta RF: 40dBm/Band, Aschur sruth singil | |
Power adjustment range 0-30dB, adjustment step size 1dB, adjustment error±0.5dB | ||
Cruinneas sioncronaithe: 0.1ppm | ||
achar jamming | Trastomhas jamming antenna treo 20W 1000-2000M, ga antenna omnidirectional 500-800M | |
Feidhmíocht wifi | Tacaíocht gaile amháin 2.4G | |
Cumhacht 20dBm | ||
Tacaíocht 802.11b/g/n | ||
Port | RJ451(WAN) Tacaíocht do rochtain áitiúil | |
N-J2 | 2 RF port（ANT0,ANT1） | |
SMA-J | WiFi antennaport (caighdeánach), Tacaíocht do rochtain áitiúil | |
SCAN antenna Sioncrónaithe | ||
calafort GPSantenna | ||
Sioncronú ama | Tacaíocht in aghaidh an bhanna sioncronaithe am GPS | |
Tacaíocht am freastalaí NTP a shioncronú, in aghaidh an bhanna | ||
Íosluchtaigh feidhmíochta uimhreacha | Ráta gabhála teirminéil díomhaoin Níos mó ná nó cothrom le 95 faoin gcéad , Ráta uimhreacha gabhála teirminéil shoghluaiste Níos mó ná nó cothrom le 90 faoin gcéad | |
Cearrbhachas cumarsáide | Bogearraí nasc gan sreang, jamming glas | |
Liosta Bán | Tacaigh le húsáideoirí liosta bán gnáthchumarsáid a scaoileadh chuig an líonra poiblí | |
Socruithe polasaí úsáideora | Tacaíocht a bhrú 4G/3G/2G roghnach | |
Am tosaithe an chórais | Níos lú ná nó cothrom le 300s | |
Tomhaltas uasta | 4 box frame total consumption >1000W | |
Toise | ||
Meáchan | ||
Ábhar | alúmanaim | |
Leibhéal Cosanta | IP32/IP65 rogha | |
Dath | Dubh | |
Cumhacht | AC220 | |
Ceanglais chomhshaoil | Indoor environment,-30 degree -55 degree ,humidity＜85％ | |
Má theastaíonn tuilleadh eolais uait, seol ríomhphost chugainn le do thoil.
